Aeromotive 18668 In-Tank A1000 700HP to 1500HP Fuel Pump With AN -10 ORB Inlet And Outlet

Designed for the custom tank builder or fabricator, the universal assembly uses o-ring clamps to positively seal the provided 3/4" tube to both the filter pickup and the fuel pump inlet, allowing for perfect placement of the pickup and ensuring superior performance.

Now custom tanks and fuel cells can easily and affordably feature an in tank fuel pump; increasing performance and drivability while extending the life span of the pump. Proper baffling and clearance will be required, but installation could not be simpler with this universal design. This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

Fuel injected engines:

• Up to 1300 HP for naturally aspirated
• Up to 1000 HP for forced air induction

Carbureted engines:

• Up to 1500 HP for naturally aspirated
• Up to 1200 HP for forced air induction

Includes 100 Micron stainless steel fuel filter pickup

Includes 9-3/4" long 3/4" aluminum tube

Includes the split nut mounting ring and the 10-24 mounting hardware

Drop in replacement for any in-tank pump utilizing a 10-bolt pattern on a 4" bolt circle

#10 inlet and outlet (7/8"-14 thread) o-ring ports

Pump measures 6-3/4" from underneath the flange to the bottom

Replacement Pump Only is part number 18010
